4 Chapter 1 - Introduction
LIGHTBAR
Figure 1-5: CenterLine Lightbar
Lightbar Specifications
Housing Material ABS/Poly carbonate alloy construction.
Dimensions 3.70” H x 9.40” W x 3.80” D / 95mm x 240mm x 100mm
Weight 0.8 lbs / 0.36 kg
Processor Intel StrongARM
Memory 16 MB Ram, 2 MB Flash
LEDs High-lumen red, yellow, and green radial light pattern and 10-char-
acter LED alphanumeric text display. Full brightness control adjust-
ment using wireless remote.
Operating Voltage 10-14 VDC
Operating Temperature 32 o to 160 o F / 0 o to 70 o C
Storage Temperature -40
o
to 185
o
F / -40
o
to 85
o
C
I/O to DGPS 1 asynchronous RS232
I/O to Control Unit Wireless link operating at 433 MHz. FCC Part 15 and Industry Can-
ada RS-210 certified. Other certifications pending.
Mounting Mounting bracket supplied. Magnetic and suction mounts are
optional.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condi-
tions: (1) This device may not cause harmful interference; and (2) this device must accept any inter-
ference received, including interference that may cause undesired operation.
QS7CL7850094
QS7CL7850107
TR19JN96.008
Changes or modifications to the product, not expressly approved by TeeJet Technologies, Inc. could
void the user’s authority as granted under Part 15 of the FCC Rules to operate the equipment.
