Control ~ Remote Builder 76
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
The Remote Builder window is used to configure the optional XAP IR Remote
Control and ClearOne Volume and Select Control Panels. These control devices are
connected to Remote Panel A or Remote Panel B— the RS-485 connectors. If you
want to create custom control assignments for presets, open the Remote Builder
from the Preset Configuration pane and select the Use in Preset option.
XAP IR Remote
The XAP IR Remote provides remote control of volume and mute for a PSR system.
You can connect up to two XAP IR Remote Controls— one to each RS-485 port. See
the XAP IR Remote user manual for more information. The XAP IR Remote has five
programmable buttons and one programmable LED. You can customize your XAP
IR Remote using the Remote Builder. To open the Remote Builder, click the
Remote Builder button on the Flow Screen (or the button in the G-Ware
toolbar).
Remote Builder
Figure 6.4. Remote Builder
Figure 6.2. Remote Builder
button on Flow Screen
Figure 6.3. Remote
Builder toolbar button
If you want to program
different button assign-
ments for use in a preset,
you will need to open the Remote
Builder from the Preset
Configuration pane (see page 55)
and select Use in Preset.
-
