MLINE - Mic/Line Adjust
This command selects/reports the setting of coarse gain adjustment on the input
channels 1-8. The three settings are 0dB, 25dB, and 55dB.
Command form: DEVICE MLINE [Value]
Argument details
Name Description
Device 0–7 or * to select all units
MLINE Command form
Channel 1–8 (selects mic inputs)
Value 0 = 0dB (line level), 1 = 55dB, 2 = 25dB, Null = current level
Example: #43 MLINE 1 2 On PSR1212 unit 3 (#43), the mic/line (MLINE)
setting for input 1 is 25dB (2).
MMAX - Maximum Number of Microphones
This command selects/reports the maximum number of microphones for each gating
group.
Command form: DEVICE MMAX [Value]
Argument details
Name Description
Device 0–7 or * to select all units
MMAX Command form
Channel 1–4, A-D (gating groups)
Value 0 = Unlimited, 1–8 = Maximum number of mics
Null = Current maximum number of microphones
Example: #42 MMAX A 4 On the PSR1212 unit 2 (#42), the max number of
mics ( MMAX) in gating group A that are allowed to gate on at any one time is 4.
MPASS - Modem Password
This command sets the current password setting for the unit when using modem
mode. The password must be entered in twice.
Command form: DEVICE MPASS [String]
Argument details
Name Description
Device 0–7 or * to select all units
MMAX Command form
String 0-12 characters, CLEAR = to clear the current password
Null to report the current password
Example: #40 MPASS CLEARONE On PSR1212 unit 0 (#40), the modem
password ( MPASS) is set to CLEARONE.
114
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Appendices ~ Appendix E: Serial Commands
Once the command is
given, the unit responds
by echoing back the
command, followed by “RE-
ENTER PASSWORD” string. The
command must then be re-
entered exactly as entered
previously. Then, the command
will be echoed back, followed by
an “OK,” indicating that the
password has been changed.
-
