Table 2–3: Supported SCSI Cables
Cable Connector
Density Pins Configuration Use
BN21W-0B Three high 68-pin A Y cable that can be attached to a
KZPSA-BB or KZPBA-CB if there
is no room for a trilink connector.
It can be used with a terminator to
provide external termination.
BN21M One low, one
high 50-pin
LD to
68-pin
HD Connects the single-ended end of
a DWZZA-AA or DWZZB-AA to
a TZ885 or TZ887.
a
BN21K,
BN21L, or
328215-00X Two HD68 68-pin Connects BN21W Y cables or wide
devices. For example, connects
KZPBA-CBs, KZPSA-BBs, HSZ40s,
HSZ50s, the differential sides of
two SCSI signal converters, or a
DWZZB-AA to a BA356.
BN38C or
BN38D One HD68, one
VHDCI HD68 to
VHDCI Connects a KZPBA-CB or KZPSA-BB
to a port on an UltraSCSI hub.
BN37A Two VHDCI VHDCI
to
VHDCI Connects two VHDCI trilinks to
each other or an UltraSCSI hub to a
trilink on an HSZ70 or HSZ80
199629-002 or
189636-002 Two high 50-pin
HD to
68-pin
HD Connect a Compaq 20/40 GB DLT
Tape Drive to a DWZZB-AA
146745-003 or
146776-003 Two high 50-pin
HD to
50-pin
HD Daisy-chain two Compaq 20/40
GB DLT Tape Drives
189646-001 or
189646-002 Two high 68-pin
HD Connect a Compaq 40/80 DLT Tape
Drive to a DWZZB-AA or daisy-chain
two Compaq 40/80 DLT Tape Drives
a Do not use a KZPBA-CB with a DWZZA-AA or DWZZB-AA and a TZ885 or TZ887. The DWZZAs and
DWZZBs can not operate at UltraSCSI speed.
Always check a SCSI cable for bent or broken pins. Be sure that you do not
bend or break any pins when you connect or disconnect a cable.
Hardware Requirements and Restrictions 2–13
