Figure 6–6: Multiple-Bus NSPOF Configuration Number 2
ZK-1707U-AI
KGPSA
Member
System
2
KGPSA
Memory
Channel
KGPSA
Member
System
1
KGPSA
Memory
Channel
Memory Channel
Interface
Fibre Channel Switch
Fibre Channel Switch
HSG 80
Controller A
HSG 80
Controller B
RA8000/ESA12000
Port 1
Port 2
Port 1
Port 2
Using Fibre Channel Storage 6–13
