Table 6–2 contains the necessary information to convert from the HSG80
unit numbers to /dev/disk/dskn and device names for the example
configuration. A blank table (Table A–1) is provided in Appendix A for use in
an actual installation.
One mirrorset, the BOOT-MIR mirrorset, will be used for the Tru64 UNIX and
cluster member system boot disks. The other mirrorset, CROOT-MIR, will be
used for the cluster root (/), cluster /usr, cluster /var, and quorum disks.
To set up the example disks for operating system and cluster installation,
follow the steps in Example 6–2.
Example 6–2: Setting Up the Mirrorset
HSG80> RUN CONFIG 1
Config Local Program Invoked
Config is building its table and determining what devices exist
on the system. Please be patient.
add disk DISK30200 3 2 0
add disk DISK30300 3 3 0
add disk DISK40000 4 0 0
add disk DISK40100 4 1 0
...
Config - Normal Termination
HSG80> ADD MIRRORSET BOOT-MIR DISK30200 DISK40000 2
HSG80> ADD MIRRORSET CROOT-MIR DISK30300 DISK40100 2
HSG80> INITIALIZE BOOT-MIR 3
HSG80> INITIALIZE CROOT-MIR 3
HSG80> SHOW BOOT-MIR 4
Name Storageset Uses Used by
--------------------------------------------------------------------
BOOT-MIR mirrorset DISK30200
DISK40000
Switches:
POLICY (for replacement) = BEST_PERFORMANCE
COPY (priority) = NORMAL
READ_SOURCE = LEAST_BUSY
MEMBERSHIP = 2, 2 members present
State:
UNKNOWN -- State only available when configured as a unit
Size: 8378028 blocks
HSG80> SHOW CROOT-MIR 4
Name Storageset Uses Used by
--------------------------------------------------------------------
CROOT-MIR mirrorset DISK30300
DISK40100
Switches:
POLICY (for replacement) = BEST_PERFORMANCE
COPY (priority) = NORMAL
READ_SOURCE = LEAST_BUSY
MEMBERSHIP = 2, 2 members present
State:
UNKNOWN -- State only available when configured as a unit
Size: 8378028 blocks
Using Fibre Channel Storage 6–37
