See the TruCluster Server Cluster Administration manual for more
information on failover pairs.
The MC2 jumpers are described in Table 5–2.
Table 5–2: MC2 Jumper Configuration
Jumper: Description: Example:
J1: Hub Mode Standard: Pins 1 to 2
1 2 3
VH0: Pins 2 to 3
1 2 3
VH1: None needed;
store the jumper on
pin 1 or pin 3
1 2 3
J3: Window Size 512 MB: Pins 2 to 3
1 2 3
128 MB: Pins 1 to 2
1 2 3
J4: Page Size 8-KB page size (UNIX):
Pins 1 to 2
1 2 3
4-KB page size (not
used): Pins 2 to 3
1 2 3
5–4 Setting Up the Memory Channel Cluster Interconnect
