Compaq AA-RHGWC-TE User Manual
Page 245
____________________
Notes
____________________
Do not connect a SCSI bus to the SCSI connectors for the
library connectors on the base modules.
We recommend that no more than two TZ89 tape drives be
on a SCSI bus.
Figure 8–11 shows a MiniLibrary configuration with two TL892 DLT
MiniLibraries and a TL890 DLT MiniLibrary expansion unit. The TL890
library robotics is on one shared SCSI bus, and the two TZ89 tape drives in
each TL892 are on separate, shared SCSI buses. Note that the pass-through
mechanism and cable to the library robotics motor is not shown in this figure.
Configuring a Shared SCSI Bus for Tape Drive Use 8–31
