64-Bit PCI-to-Fibre Channel Host Bus Adapter User Guide
_____________________
Caution
_____________________
Static electricity can damage modules and electronic components.
We recommend using a grounded antistatic wrist strap and a
grounded work surface when handling modules.
1.
If necessary, install the mounting bracket on the KGPSA-BC module.
Place the mounting bracket tabs on the component side of the board.
Insert the screws from the solder side of the board.
2.
The KGPSA-BC should arrive with the gigabit link module (GLM)
installed. If not, close the GLM ejector mechanism. Then, align the
GLM alignment pins, alignment tabs, and connector pins with the holes,
oval openings, and board socket. Press the GLM into place.
The KGPSA-CA does not use a GLM, it uses an embedded optical
shortwave multimode Fibre Channel interface.
3.
Install the KGPSA in an open 32- or 64-bit PCI slot.
4.
Insert the optical cable SC connectors into the KGPSA-BC GLM or
KGPSA-CA SC connectors. The SC connectors are keyed to prevent
their being plugged in incorrectly. Do not use unnecessary force. Do not
forget to remove the transparent plastic covering on the extremities
of the optical cable.
5.
Connect the fiber-optic cables to the shortwave Gigabit Interface
Converter modules (GBICs) in the DSGGA, DSGGB, or DSGGC Fibre
Channel switch (or one of the seven fixed shortwave optical transceivers
in the DS-DSGGC-AA).
6.5.2.2 Setting the KGPSA-BC or KGPSA-CA to Run on a Fabric
The KGPSA host bus adapter defaults to the fabric mode, and can be used in
a fabric without taking any action. However, if you install a KGPSA that
has been used in the loop mode on another system, you will need to reformat
the KGPSA nonvolatile RAM (NVRAM) and configure it to run on a Fibre
Channel fabric configuration.
Use the wwidmgr utility to determine the mode of operation of the KGPSA
host bus adapter, and to set the mode if it needs changing (for example
from loop to fabric).
______________________
Notes
______________________
You must set the console to diagnostic mode to use the wwidmgr
utility for the following AlphaServer systems: AS1200, AS4x00,
6–24 Using Fibre Channel Storage
