Compaq AA-RHGWC-TE User Manual
Page 134
Figure 6–2: Fabric Topology
N_Port
Node 1
Node 2
Transmit
Receive
Transmit
Receive
Transmit
Receive
Transmit
Receive
Transmit
Receive
Transmit
Receive
Transmit
Receive
Transmit
Receive
F_Port
Fabric
Node 3
Node 4
F_Port
F_Port
F_Port
N_Port
N_Port
N_Port
ZK-1536U-AI
6.2.2.3 Arbitrated Loop Topology
In an arbitrated loop topology, frames are routed around a loop created by
the links between the nodes.
In an arbitrated loop topology, a node port is called an NL_Port (node loop
port), and a fabric port is called an FL_Port (fabric loop port).
Figure 6–3 shows an example arbitrated loop topology.
6–8 Using Fibre Channel Storage
