Page 121
Figure 5–3 through Figure 5–8 show a three-node standard hub
configuration being upgraded from MC1 to MC2.
Figure 5–3: MC1 to MC2 Standard Hub Rolling Upgrade: Initial
Configuration
AlphaServer
Member
System 1
MC1
MC1
AlphaServer
Member
System 2
MC1
MC1
MC1 Hub
# 1
ZK-1522U-AI
MC1 Hub
# 2
AlphaServer
Member
System 3
MC1
MC1
Setting Up the Memory Channel Cluster Interconnect 5–21
