Example 7–4: Displaying Console Serial Bus Information (cont.)

C3

CPU3/SROM

V5.0-7

ON

C0

IOR0

ON

C1

IOR1

ON

31

PSM

T05.4

(03.24/01:09)

T4.0 (07.06)

ON

SrvSw: NORMAL

31

XSROM

T05.4

(03.24/02:10)

C4

CPU0/SROM

V5.0-7

ON

C5

CPU1/SROM

V5.0-7

ON

C6

CPU2/SROM

V5.0-7

ON

C7

CPU3/SROM

V5.0-7

ON

32

PSM

T05.4

(03.24/01:09)

T4.0 (07.06)

ON

SrvSw: NORMAL

32

XSROM

T05.4

(03.24/02:10)

C8

CPU0/SROM

V5.0-7

ON

C9

CPU1/SROM

V5.0-7

ON

CA

CPU2/SROM

V5.0-7

ON

CB

CPU3/SROM

V5.0-7

ON

C8

IOR0

ON

C9

IOR1

ON

33

PSM

T05.4

(03.24/01:09)

T4.0 (07.06)

ON

SrvSw: NORMAL

33

XSROM

T05.4

(03.24/02:10)

CC

CPU0/SROM

V5.0-7

ON

CD

CPU1/SROM

V5.0-7

ON

CE

CPU2/SROM

V5.0-7

ON

CF

CPU3/SROM

V5.0-7

ON

40

HPM

T05.4

(03.24/01:18)

X4.1 (08.18)

ON

E0

SCM MASTER

T05.4

(03.24/01:21)

T4.2 (09.08)

ON

E1

SCM SLAVE

T05.4

(03.24/01:21)

T4.2 (09.08)

ON

Ineligible

1

The console serial bus (CSB) node ID, or in the case of a QBB, the CPU
number in the QBB. The CSB node address ranges are as follows:

10 to 1f: PCI backplane manager (PBM) — The CSB node ID is
based on the PCI drawer node ID setting.

e0 to e7: System control manager (SCM) — The CSB node ID is also
based on the PCI drawer node ID setting.

30 to 37: Power system manager (PSM) — Based on the hard QBB
ID (QBB 0 - 7)

40: Hierarchical switch power manager (HPM)

C0 to CF: In response to the SCM show csb command, the PSM
provides CSB node addresses for the CPUs and I/O risers even
though they are not on the console serial bus. This enables SCM
commands to be directed at any specific CPU, for instance power
off -cpu c4

. The PSM responds to SCM commands and powers

the CPU on or off.

2

The type of CSB node:

PBM (PCI backplane manager)

PSM (Power system manager)

HPM (Hierarchical switch power manager)

Using GS80, GS160, or GS320 Hard Partitions in a TruCluster Server Configuration 7–17
