16BAppendix A: Specifications
122 TruVision DVR 11 User Manual
TVR 1104 TVR 1108 TVR 1116
Playback resolution 4CIF / 2CIF / CIF / QCIF
Synchronous playback 4-ch 8-ch 16-ch
Hard disk
SATA 2 SATA interfaces
Capacity Models without CD/DVD burner: 2 HDDs. Up to 2TB capacity for
each disk
Models with CD/DVD burner: 1 HDD. Up to 2TB capacity
External interface
Network interface 1 RJ45 10M / 100M Ethernet interface
Serial interface 1 RS-232 interface (for ProBridge, Challenger, Technical Support);
1 RS-485 interface (for PTZ control or KTD405 keyboard control)
USB interface 2, USB 2.0
Alarm in 4
Alarm out 1
Miscellaneous
Power supply 12 VDC
Power consumption
(without HDD or DVD-R/W)
≤ 15 W ≤ 20 W ≤ 30 W
Operating temperature -10 to +55 ºC (14 to 131 °F)
Relative humidity 10 to 90%
Chassis 1.5U chassis
Dimensions (W x H x D) 362 Ч 330 Ч 78 mm (14.25 Ч 13.0 Ч 3.07 in.)
Weight
≤ 3 kg (6.6 lb.) (without HDD or DVD-R/W)
