TruVision DVR 11 User Manual 121
Appendix A
Specifications
TVR 1104 TVR 1108 TVR 1116
Video & audio input
Video compression H.264
Analog video input 4-ch,
BNC
(1.0 Vp-
p, 75 Ω),
PAL /NTSC self-
adaptive
8-ch,
BNC
(1.0 Vp-
p, 75 Ω),
PAL /NTSC self-
adaptive
16-ch,
BNC
(1.0 Vp-
p, 75 Ω),
PAL /NTSC self-
adaptive
Audio compression G711 G722
Audio input 4-ch, RCA (2.0 Vp-
p, 1 kΩ)
Two-way audio 1-ch (reduplicated with audio input 1), RCA (2.0 Vp-
p, 1 kΩ)
Video & audio output
HDMI output 1-ch,
Resolution: 1920 × 1080P / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024
/ 60 Hz,1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
VGA output 1-ch,
Resolution: 1920 × 1080P / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024
/ 60 Hz,1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output 1-ch, BNC (1.0 Vp-
p, 75 Ω),
Resolution: PAL: 704 × 576; NTSC: 704 × 480
Video loop output 4-ch 8-ch 16-ch
Encoding resolution 4CIF / 2CIF / CIF / QCIF
Frame rate 8 fps at 4 CIF, 15 fps at 2CIF, 25 fps (PAL) / 30 fps (NTSC) at
CIF/QCIF
Total frame rate: 120 fps
Video bit rate 32 to 4096 Kbps, or user defined (max. 3072 Kbps)
Audio output 1-ch, RCA
Audio bit rate 64 Kbps
Dual-stream Support | (Sub-stream at CIF: 6 fps,
QCIF: 25 fps (PAL) / 30 fps (NTSC))
Stream type Video, Video & Audio
