51

English

Interface Selection

Start with the auto-chart program
running.

You can change the port in the
interface selection area. For changing
the port, click on the drop down field
and select “auto”.

If the instrument was not detected
make sure it was installed as COM

Interface

146

1. Installation of the driver

Insert the auto-chart CD-ROM.

As you plug the device to the USB
port of the computer, it is recognized
by the system and the hardware
assistant opens.

Choose “Install from a list” and click
the button “Next”. Select the folder
“USB Driver” from the auto-chart CD.

The driver setup begins. Note that if a
window displays a choice of buttons
to “Continue Anyway” or “Stop Instal-
lation” click on “Continue Anyway”.

The driver’s installation is completed
by clicking the “Finish” button.

After short time the hardware assistant
opens for the port installation.

2. Installation of USB serial port

Continue the installation as described
above by following the instructions.

After the setup is completed, follow
any on-screen instruction (e.g. “Restart
Computer”).

port < 10. Refer to the “Device Mana-
ger” of the operating system (Start >
Settings > Control Panel > System >
Hardware).
