ALTANA Wave-Scan II - Manual (Page 28)

27
English
Measure 9
The name of the checkzone to be
measured first, appears on the left side
of the display.
The number of performed and
predefined measurements (e.g. 2 of 3)
appear in the upper right corner.
Once the number of measurements for
the checkzone is reached, a double
audio signal is heard.
The display shows the results of the
measurement and indicates that the
measurement of the checkzone is
complete (e.g.3/3).
Pressing briefly the operate button
allows the next checkzone to appear
in the display.
The instrument is ready for the next
measurement.
Once all checkzones have been
measured, the instrument returns to
the Measure menu.
