6.1.1 Air Filter Cleaning
For the heater to work properly the ai
r filter must be clean. A dirty air filter can cause a power
input reduction of the unit, resulting in system malfunctions. To clean the air filter, perform the
following:
Cleaning the Air Filter
1. Follow the steps in Section 6.1.15 to gain access to the internal components.
2. Pull down with a rotating motion
the air filter “B” as per Figure 6-8.
3. Pull out
the air filter and remove it from the unit.
4.
Clean the surface of the air filter using compressed air.
5.
Reassemble the air filter, noting the orientation arrow on the front of the filter.
Figure 6-8: Removing the Air Filter for Cleaning
