A-4 LK-H1W-M-NOA-E
Appendices
A
Overall scaling
Implement the scaling setting so
that span value of the scaling
setting is 9.999 or less. Inclination of the scaling setting
exceeds 9.999. Set the input/output values of
scaling setting so that inclination
of the scaling setting is 9.999 or
less.
Offset
Illegal entry.
Enter a value in the range of
(–99.9999 to 99.9999). The offset setting input column
is left blank. Or any character
other than numerical value, or a
value exceeding the settable
range is set in the offset setting
input column. Enter a value from –99.9999 to
99.9999 as an offset.
Upper limit and lower limit of tolerance
Illegal entry.
Enter a value in the range of
(–99.9999 to 99.9999). The tolerance upper limit/lower
limit column is left blank. Or any
character other than numerical
value, or a value exceeding the
settable range is set in the
tolerance upper limit/lower limit
input column. Enter a value from –99.9999 to
99.9999 for the upper and lower
limit values.
Set the value in the way that the
lower limit value is smaller than
the upper limit value. A value that is larger than the upper
limit value is set in the tolerance
lower limit value column. Enter a value that is smaller than
the upper limit value in the
tolerance lower limit column.
Tolerance hysteresis
Illegal entry.
Enter a value in the range of
(0 to 99.9999). The tolerance hysteresis column
is left blank. Or any character
other than numerical value, or a
value exceeding the settable
range is set in the tolerance
hysteresis input column Enter a value from 0 to 99.9999
for the tolerance hysteresis.
A tolerance hysteresis value that
exceeds [Upper limit value] –
(minus) [Lower limit value]
cannot be set. A value that exceeds the
tolerance measurement range
([Upper limit value] – (minus)
[Lower limit value]) is set in the
tolerance hysteresis. Enter a positive value that is
smaller than the tolerance
[Upper limit value] – (minus)
[Lower limit value] in the
tolerance hysteresis.
Analog scaling measured value
Illegal entry.
Enter a value in the range of
(–99.9999 to 99.9999). The analog scaling measured
value is left blank. Or any
character other than numerical
value, or a value exceeding the
settable range is set in the
column of analog scaling
measured value. Enter a value from –99.9999 to
99.9999 for the analog scaling
input.
The identical value cannot be
set for the Input values. The identical value is set in both
of the Input value-1 column and
Input value-2 column of the
analog scaling measured value. Enter different values in the
Input value-1 column and Input
value-2 column of the analog
scaling measured value.
Error message Cause Remedy
* ( ) The value within the parenthesis differs depending on the setting specified in [Minimum display unit].
