KEYENCE LK-H1W - Manual (Page 71)

3-43 LK-H1W-M-NO3-E
3 Operations and Functions of Software
3
Saving the Setting File
1
Click the [Save] button of the main screen.
The same operation is executed by selecting [Save Setting File] from [File] on the menu
bar.
The [Save As] window is displayed.
2
Open the folder where you want to save the setting file, and enter the filename
to be used for saving, in [File name].
[LK-G_config.ldt] is entered in this example.
The extension ".ldt" is automatically added to the saved file to indicate that the file is the
setting file of the controller.
3
Click the [Save] button.
1
Reference
2 3
Reference
