KEYENCE LK-H1W User Manual

Page 65

3-37

LK-H1W-M-NO3-E

3 Operations and Functions of Software

8. Display Position Change

Move the display position of waveform.

The waveform display position can be moved only when waveform is being displayed.

9. Waveform Name

Give an arbitrary name to the waveform.

• A maximum of 16 alphanumeric characters (excluding "," (comma) and "." (period))

can be used in a name of waveform.

• Name can be given to waveform only when waveform is being displayed.

10. Change the Waveform Color

Waveform color can be set.

Waveform color can be set only when waveform is being displayed.

11. Display of Measured Value Waveform

Waveform of the readout measurement value is displayed.

12. Cursor Information

List of cursor information is displayed.

13. Read from File

Reads out the storage data from file.

14. Save in File

The stored data is saved in file.

The stored data is saved in file in the CSV format.

15. Exit

Closes the [Data Storage] window.

16. Help

Opens the Help file of "LK-Navigator".

Note

Reference
