3-33 LK-H1W-M-NO3-E
3 Operations and Functions of Software
3
2. Waveform display change bar
Enlarge/Reduce
Waveform can be displayed after it is enlarged/reduced of its size in the vertical and
horizontal directions.
Moving the display position
Waveform display position can be moved up/down.
ABLE
When [Transparent object-2] is selected by [Measurement Mode], the ABLE processing is
applied to the waveforms 1 through 4, and the resultant waveforms after the processing
are displayed.
3. Model display
Models of the heads that are showing their waveforms are indicated.
4. View Received Light Waveform
Displays waveform of the received light data. The white vertical line on the waveform
indicates the present measuring position. The method to read the waveform is explained
below.
• Horizontal axis
: It indicates position of the received light waveform. As it is
positioned closer to the left end, it indicates that the received
light is positioned closer to the head.
• Vertical axis : It indicates intensity of the received light. As it goes higher, it
indicates that the received light is more intense.
• Waveform display : Waveform after the controller applies the ABLE processing is
displayed.
5. Copying the screen image
The present waveform is copied to the clipboard.
6. Double-writing the waveforms
While the waveform that is obtained at the time of clicking is kept displayed, double-
writing of the present waveform over the above-mentioned waveform is executed so that
the double-writing waveforms are displayed.
7. Exit
Closes the [Head-A Received Light Waveform Display] window.
8. Help
Opens the Help file of "LK-Navigator".
For ABLE, refer to "LK-G Series User’s Manual" refer to "LK-G Series User’s Manual" refer
to "Chapter 3 Function Settings" (3-1 page)..
