4. Click on the radio button corresponding to the desired analysis
action:
The Open selected Analysis option will open the selected analysis
without providing an opportunity for modification of the analysis.
The View and Open Existing Configuration option will permit the
user to view/modify an existing analysis (see notes and procedure
following).
The Define New Analysis option will create a new analysis (see
notes and procedure following).
NOTES If no analyses have been created, none will appear in the text box on the
right side of the window, and only the Define New Analysis option will be
available. If you have already configured and saved an analysis, its
name will appear in the list box. If you select an existing configuration
and click OK, the analysis will be performed using the current configura-
tion settings. It will not be necessary to complete the remaining steps in
this procedure.
5. Click OK . If the Open Selected Analysis option was selected, the
analysis will be immediately displayed. If the View and Open
Existing Configuration or Define New Analysis options were
selected, the Analysis Configuration window will appear. The
Analysis Configuration window consists of tabbed pages with filter
options appropriate for the analysis.
6. Click on the tab corresponding to the filter you wish to set and
complete the configuration options. For further information on
selecting filter options, see the following sections of this chapter, as
well as the chapter corresponding to the specific analysis.
7. When you have completed the configuration, click OK . The program
will prompt you to save the configuration.
8. Click Yes to save the configuration. The Save Configuration
window will appear. Type the name of the new configuration in the
Save As: field.
Or click the name of a preexisting configuration in the Existing
Configurations list box (If you select this option, you will replace
the existing configuration with the new configuration settings).
9. Click OK . The analysis will be performed and displayed using the
selected configuration settings.
NOTES You may click Cancel from the Save Configuration window to exit without
saving configuration changes.
You may display several analyses simultaneously by repeating the
instructions above. Use the tiling options available from the Window
menu to display multiple analyses in the desired window format (horizon-
tal, vertical or cascade view options are available).
