Filters

Complete selection of Date and Sample/Error filter options per
the instructions in Chapter 13.

Ports

b. Click the

Port Output Format

tab and click

Add Port

from the

button options to open the

Select Port

window. Select the desired

serial port(s) and/or files for output and verify the configuration
settings for each. Then Click

. Added ports will be displayed in

the port list box.

NOTE

If you select NEW FILE for output, click the

button to open

the Windows Save As: box. Select the desired directory and type the
desired file name in the File Name: text box. If you select an existing file,
ASCII port analysis data will be appended to the file.

Make certain that you have selected the desired port for configuration by
clicking on the port name in the Add Port list box prior to selecting output
data and formatting options for that port. OUTPUT FOR EACH ADDED
PORT MUST BE CONFIGURED SEPARATELY (see note below).

Configuring output

d. Select the desired port/file for configuration by clicking the name

of the port/file in the port list box. Then click the radio button
corresponding to the desired locale format (U.S. or local). Your
choice will determine the formatting of numeric data, dates and
choice of decimals or commas as placeholders.

Delaying serial output

You may delay data transmission of serial output for a time
parameter you specify by clicking the

Delay

button to insert the

delay code into the Configure list box, Header or Footer. The

Delay Configuration

window will appear. To set the time of the

Delay, type a numeric value in the appropriate field, and click on
one of the radio buttons to select the correct unit of time. Then
click

Selecting output data

Click the buttons corresponding to the data types you wish to
output on the report. As you do so, the appropriate coding for the
output analysis will be automatically inserted in the text box.

NOTE

For some data output options, you will need to select the desired output
field length using the spin controls

provided in the Format Data

Output window. Experienced users may type code directly into the text
box by clicking in the text box to place the cursor at the appropriate point.
The text box information may also be manipulated using the mouse click-
and-drag technique to highlight data and then using standard Windows

cut (

-X), copy (

-C), and paste (

-V) keyboard combinations. In

this way, formatting data can easily be copied from one port configura-
tion to another.
