Table D-2 lists the model codes and spring torque constants for each Rheometer model.
Table D-2
MODEL
TK
MODEL CODE ON DV3T
SCREEN
DV3TLV
0.09373
LV
2.5DV3TLV
0.2343
L3
5DV3TLV
0.4686
L5
1/4 DV3TRV
0.25
RQ
1/2 DV3TRV
0.5
RH
DV3TRV
1
RV
DV3THA
2
HA
2DV3THA
4
A2
2.5DV3THA
5
A3
DV3THB
8
HB
2DV3THB
16
B3
2.5DV3THB
20
B5
The full scale viscosity range for any DV3T model and spindle may be calculated using the equation:
Full Scale Viscosity Range [cP] = TK * SMC * 10,000
RPM
where:
TK = DV3T Torque Constant from Table D-2
SMC = Spindle Multiplier Constant from Table D-1
The Shear Rate calculation is:
(Shear Stress (D/cm
2
)) = Viscosity (P) * Shear Rate (1/sec)
= TK * SMC * SRC * TORQ
