Brookfield Engineering Labs., Inc. Page 10 Manual No. M13-2100
Note: The DV3T must be earth grounded to ensure against electronic failure!!
7) Turn the power switch to the ON position and allow the rheometer to warm up for 10
minutes before performing autozero.
8) For Cone/Plate models, refer to Appendix A.
9) If appropriate, connect USB cable (DVP-202) to USB port for connection of DV3T to
PC or printer.
10) Review Read Me file. The Read Me file contains notes on the DV2T Firmware. This file
can be found on the CD that contains the PG Flash Software.
Temperature
Probe
USB B
USB A
On/Off
Switch
Ethernet
(Future Use)
Power Input
Temperature
Controller
Figure I-2
