39
Broadcast Enables or disables continuous send. To enable continuous
send, a group number must be entered under GrouP. This
number defines the group to be activated at each display
update.
Autosend Enables or disables autosend. To enable auto send, a
group number must be entered under GrouP. This
number defines the group to be printed each time weight
stabilizes above 1% capacity. The weight must fall below
1% capacity for the indicator to initiate another print.
Choose Save so information is saved in the database
rather than outputting to the serial port. If the database is
full, the data cannot be stored and the autosend trigger is
ignored.
Protocol A protocol is defined as the set of input characters
assigned to specific actions for each port. Under this item
you choose a port, choose an input number, assign an
ASCII character to the action, and choose the associated
action from the following list (see note at left):
Units - Switches indicator to the next available unit of
measure.
Unit 1 - Switches indicator to Unit 1, if available.
Unit 2 - Switches indicator to Unit 2, if available.
Unit 3 - Switches indicator to Unit 3, if available.
Select - Switches indicator to next available display
mode.
Force - Switches display to the Force mode.
Top - Switches display to the Peak mode.
First - Switches display to the 1st Peak mode.
Reset - Causes a Peak Reset.
Send - Causes a Data Send to occur. Use Group to
specify which group to output.
Reply - Specifies that a specified group is to be output.
Use Group to specify which group to output.
Save - Causes information selected by the record
definition is to be stored in the database. If the
database is full this command is ignored.
Zero - Performs a Zero function.
Default Groups
Group # Port 1 Port 2 Port 3 Inhibit
1 Layout 5 None None Yes
2 Layout 6 None None Yes
3 Layout 7 None None Yes
4 Layout 8 None None Yes
5 Layout 10 None None No
6 Layout 14 None None No
Except for Reply and Save, the
actions at right can only be executed
if the character is received while the
indicator is in the Display mode.
Reply and Save can be executed
when the indicator is in Display
mode and also in the User Menu.
