37
Hour Transmits time in 12 hour or 24 hour format, depending on
current setting.
Day Transmits the date in mm/dd/yy format.
Status Transmits the current status.
Transmitted as a single character. The bits appear as follows:
011LEBM, where L is set to logic 1 when a Low voltage
condition exists; logic 0 otherwise. E is set to 1 when an a-d
Error condition exists; 0 otherwise. B is 1 when the measure-
ment is Beyond displayable range (over- or under-capacity); 0
otherwise. And M is set to logic 1 when an in-motion condi-
tion exists; set to logic 0 when the measurement is stable.
The upper four bits are set to 0011 to cause the value to be
printed as a digit or symbol in row 3 of the ASCII character
set.
*Label Transmits the chosen label. Choose from Force, Top, First,
Display and Id.
Units Transmits the unit of measure label.
Loadcell Outputs the currently selected loadcell number.
Cell Type Outputs the label for the type of loadcell; tension, compres-
sion, clockwise, counterclockwise and mode for bidirectional
cells.
*Layout Allows you to embed another layout within the current
layout. Displayed as Use n. Choose the layout number, n, you
want to print as part of the current layout.
*Delay Use this to specify a time delay in seconds from 0-255.
Record Transmits the currently selected record number.
Db. Force Transmits the force value stored in the currently selected
database record.
Db. Top Transmits the peak value stored in the currently selected
database record.
Db. First Transmits the 1st peak value stored in the currently selected
database record.
Db. Disp. Transmits the displayed value stored in the currently selected
database record.
Db. Sel. Transmits the selected value stored in the currently selected
database record.
Db. Label Transmits the Force, Peak, or 1st Peak label stored in the
currently selected database record.
Db. Cell Transmits the loadcell number stored in the currently selected
database record.
Db. Type Transmits the cell type label stored in the currently selected
database record.
Db. Units Transmits the unit of measure stored in the currently selected
* - denotes items that require
detailed information. For example: if
“LABEL” is inserted within a layout,
you must specify the label to be
printed; if “SP” is inserted, you must
specify the number of spaces to be
transmitted.
