CardioPerfect Workstation
Exercise ECG Module - User Manual
DIR 80012335 Ver. E 77 / 83
14. Function keys
The Welch Allyn CardioPerfect module is, just like all Windows applications, designed for
working with the mouse. However, there might be situations in which working with the
keyboard can be quicker. Therefore a number of functions within the Welch Allyn
CardioPerfect module can also be selected directly using the keyboard. Here is a list of all
available keyboard shortcuts in this module, for a more general function key description
please refer to the Workstation manual:
Real Time Monitor
Key
Function
F2 Start/stop test
F3 Baseline filter on/off
F4 Muscle filter on/off
F5 Blood pressure measurement
F6 Insert comment
F7 Insert Perception event
F8 Print
F9 Go to next stage
F10 Hold stage
F11 Go to next phase
F12 Emergency stop
[ALT]+[F9] Change load
[CTRL]+[DOWN] Change load: Decrease load of ergometer or decrease elevation of
treadmill. The control dialog will appear.
[CTRL]+[UP] Change load: Increase load of ergometer or increase elevation of
treadmill. The control dialog will appear.
[CTRL]+[ →] Change load: Increase speed of treadmill. The control dialog will
appear.
[CTRL]+[ ←] Change load: Decrease speed of treadmill. The control dialog will
appear.
[CTRL]+[1] Change monitor style to 12 leads
[CTRL]+[6] Change monitor style to 6 leads
[CTRL]+[3] Change monitor style to 3 leads
[PgUp] Show previous lead group, in 3 or 6 lead monitor.
[PgDn] Show next lead group, in 3 or 6 lead monitor.
[ALT]+[0] Set the ST reference point to J+0
[ALT]+[2] Set the ST reference point to J+20
[ALT]+[4] Set the ST reference point to J+40
[ALT]+[6] Set the ST reference point to J+60
[ALT]+[8] Set the ST reference point to J+80
[ALT]+[D] Set the ST reference point to Dynamic
[INS] Inserts a user event in the recording
[Esc] Exit the Real time monitor, cannot exit when recording is active.
