CardioPerfect Workstation
Exercise ECG Module - User Manual
DIR 80012335 Ver. E 22 / 83
Depending on the type of event, the following dialog will appear:
Dyspnea and Chest pain
The Borg CR10 scale is used to add
dyspnea and chest pain parameters to the
test.
Perceived exertion
The Borg RPE scale is used to add Patient
Perceived Exertion to the test.
0 Nothing at all
0.3
0.5 Extremely weak
0.7
1 Very weak
1.5
2 Weak
2.5
3 Moderate
4
5 Strong
6
7 Very strong
8
9
10 Extremely strong
* Absolute maximum
6 No exertion at all
7
8
9 Very light
10
11
Light
12
13
Somewhat hard
14
15
Hard (heavy)
16
17
Very hard
18
19
Extremely hard
20 Maximum exertion
2.3.5. Duke Treadmill Score
The Duke Treadmill Score (DTS) is shown in the Summary tab if selected. See page 55 for
more information on selecting the DTS and section 15 for more information on the DTS
calculation.
Note: The Duke Score is not applicable for pharmacological stress testing; it is only
applicable if the selected exercise device is physically used.
The Duke Score is not calculated if the Test type is not “Exercise”
2.3.6. Add a comment
During recording, you can make notes about, for example, the state of the patient. You can
choose from predefined comments or type in your own comment.
To add a comment during recording:
1. Click the Comment button in the Real-time monitor.
2. In the Comment dialog box, either use the arrow to select a comment from the list or
type in your own comment.
Extremely light
