MEP-5061/5063/5065/5071/5073
2
Installation Guide
© 2013 KMC Controls, Inc.
029-019-01xE
KMC Controls, Inc.
19476 Industrial Drive
New Paris, IN 46553
574.831.5250
www.kmccontrols.com
Important Notices
The material in this document is for information
purposes only. The contents and the product it
describes are subject to change without notice.
KMC Controls, Inc. makes no representations or
warranties with respect to this document. In no event
shall KMC Controls, Inc. be liable for any damages,
direct or incidental, arising out of or related to the
use of this document.
Maintenance
No routine maintenance is required. Careful instal-
lation will also ensure long term reliability and
performance.
Wiring
•
Connect the common to the “COM” terminal.
•
Connect the clockwise 24 VAC lead to the “CW”
terminal.
•
Connect the counterclockwise 24 VAC lead to the
“CCW” terminal.
Wiring Detail
–
24 VAC
CW
CCW
COM
~
–
More Information
For specifications and
list of accessories, see
the
.
For information about
auxiliary switches, see
the
series on the
.
For information about a
rotary feedback poten-
tiometer, see the
.
