KMC Controls SAE-1152(OLD Style Board w/ LEDs) - Manual (Page 6)

Menu Configuration Continued
Press
9. RELAY 2 DEL=2MIN
D11 and D12 flash three times to indicate this
mode.
No LEDs lit = 0 minutes
D9 lit = 1 minute
D10 lit = 2 minutes, etc.
The factory default is 2 minutes.
Press
NOTE: Item 10 is only available if the voltage
jumper is installed, otherwise the program skips
directly to step 11.
10. CALIBRAT 5V x
D11 and D13 flash three times to indicate this
mode. The value is shown on the LEDs as a 5
bit binary number. This item allows
calibration of the 5 VDC output signal.
Press
NOTE: Menu items 11 and 12 are only available
if the current jumper is installed, otherwise the
program skips directly to step 13.
11. CALIBRAT 4mA x
D12 and D13 flash three times to indicate this
mode. The value is shown on the LEDs as a 5
bit binary number.
Press
12. CALIBRAT 20mA x
D9 and D10 and D11 flash three times to
indicate this mode. The value is shown on the
LEDs as a 5 bit binary number.
Press
13. MENU QUIT
D9, D11 and D13 flash continuously to indicate
this mode. Press the key to exit the
menu and return to normal operation.
