Figure 7 SignalHawk Start Menu - Vector Network Analyzer

Item

Description

1

Name of measurement being used

2

Soft keys

3

Power source icon (AC, battery, or battery charging)

4

Go to the Help menu. See “Help Menu Key” on page 10.

5

Go to the Utilities menu. See “Utilities” on page 125.

6

Measurement mode lists

7

Menu keys

8

Selected measurement (highlighted)

9

Name and brief description of highlighted measurement

10

Current active operating mode
