137
For Spectrum Analyzer Only
Specifications
SignalHawk Models
For Spectrum Analyzer Models SH-362S, SH-361S and SH-36S
Erratic antenna test
measurements.
Bad calibration combo. Use a different calibration
standard.
Model Number Model Name
SH-362S 2-Port VNA (1.6 MHz to 3.6 GHz) and
Spectrum Analyzer (100 kHz to 3.6 GHz)
SH-361S 1-Port VNA (1.6 MHz to 3.6 GHz) and
Spectrum Analyzer (100 kHz to 3.6 GHz)
SH-362 2-Port VNA (1.6 MHz to 3.6 GHz)
SH-36S Spectrum Analyzer (100 kHz to 3.6 GHz)
Frequency
Range 100 kHz to 3.6 GHz
Resolution 1 Hz
Uncertainty ± 1 ppm (2

) of measured frequency
Aging ± 1 ppm / year (2

)
Temperature drift ± 1 ppm / °C (2

)
Span 1 kHz to 3598.4 MHz; 0 Hz (zero span)
Spectral Purity, Max @ 1 GHz
30 kHz from carrier -85 dBc / (RBW Hz)
1/2
100 kHz from carrier -100 dBc / (RBW Hz)
1/2
1 MHz from carrier -124 dBc / (RBW Hz)
1/2
Sweep Time: 2.2 to >2000 s, full span;
1 ms to 100 s, zero span (Time Domain)
Displayed Data Points 705
Resolution Bandwidth (RBW): 100 Hz to 1 MHz in 1, 3, 10 steps
Video Bandwidth (VBW): 10 Hz to 300 kHz in 1, 3, 10 steps
Amplitude
Display Range -150 dBm to +30 dBm
Intermodulation-Free Dynamic
Range 66 dB; Third-order IM products,
Two -20 dBm inputs, Reference = -10 dBm
Displayed Average Noise Level –135 dBm; 24 dB gain, 100 Hz RBW, 10 Hz
VBW, average detection
