152
* - Recommended for field strength antennas.
DIRECTIONAL POWER SENSOR
Frequency Range
Element dependent, 2 MHz to 2.7 GHz
Power Range
Element dependent, 125 mW to 1 kW full
scale
Measurements performed:
True Average Power, Peak
Forward Power (element dependent).
Calculations Performed: VSWR, Return Loss, Reflection
Coefficient
Accuracy
True Average Power, ± 5% of reading (15 °C to
35°C), ± 7% of reading (-10 °C to 50°C), Peak Power, ±8%
of full scale
5010B 1
DIRECTIONAL POWER SENSOR, TETRA VERSION
Frequency Range
Element dependent, 2 MHz to 2.7 GHz
Power Range
Element dependent, 125 mW to 1 kW full
scale
Measurements performed:
True Average Power, Peak
Forward Power (element dependent).
Calculations Performed: VSWR, Return Loss, Reflection
Coefficient
Accuracy
True Average Power, ± 5% of reading
(15 °C to 35°C), ± 7% of reading (-10 °C to 50°C)
5010T 1
TERMINATING POWER SENSOR
Frequency Range
40 MHz - 4.0 GHz
Power Range
-20.000 to +10.000 dBm (10.0010 μW to
10.000 mW)
Measurements performed:
True average power.
Accuracy
± 5% of Reading. When operating below 100
MHz and above 40 °C, add 1%.
5011 1
TERMINATING POWER SENSOR, EXTENDED
FREQUENCY
Frequency Range
40 MHz - 12 GHz
Power Range
-20.000 to +10.000 dBm (10.0010 μW to
10.000 mW)
Measurements performed:
True average power.
Accuracy
± 5% of Reading. When operating below 100
MHz and above 40 °C, add 1%
5011-EF 1
Description
Part No. Qty
