151
External Power Sensors
Description
Part No. Qty
WIDEBAND POWER SENSOR
Frequency Range
5012B: 350 MHz - 4.0 GHz
5016B: 350 MHz - 4.0 GHz
5017B: 25 MHz - 1.0 GHz
5018B: 150 MHz - 4.0 GHz
5019B: 25 MHz -1.0 GHz
Power Range
5012B: 150 mW - 150 Watts Avg. 400 Watts Peak
5016B: 25 mW - 25 Watts Avg. 60 Watts Peak
5017B: 500 mW - 500 Watts Avg. 1300 Watts Peak
5018B: 100 mW - 25 Watts Avg. 60 Watts Peak
5019B: 100 mW - 100 Watts Avg. 260 Watts Peak
Measurements performed:
Peak power, true
average power and Duty Cycle.
Calculations Performed:
VSWR, Return Loss, Reflection
Coefficient, Crest Factor, Average Burst Power and CCDF.
Duty Cycle (D)
.001 to 1.0
Average Power Accuracy
5012B: ±4% of reading, + 0.05 Watts
5016B: ±4% of reading, + 0.008 Watts
5017B: ±4% of reading, + 0.17 Watts
5018B: ±4% of reading, + 0.008 Watts
5019B: ±4% of reading, + 0.04 Watts
Burst Power Accuracy
5012B: ±6% of reading, +0.05/D Watts
5016B: ±6% of reading, +0.008/D Watts
5017B: ±6% of reading, +0.17/D Watts
5018B: ±6% of reading, +0.008/D Watts
5019B: ±6% of reading, +0.04/D Watts
Peak Envelope Power Accuracy
5012B: ±7% of reading, +0.20 Watts
5016B: ±7% of reading, +0.05 Watts
5017B: ±7% of reading, +0.70 Watts
5018B: ±7% of reading, +0.05 Watts
5019B: ±7% of reading, +0.13 Watts
CCDF = ±0.2% typical
5012B,
5016B,
5017B,
5018B, &
5019B 1
