Section 4: QBox Configuration and Operation

QBox operating system

Configure and test the QBox

QBox
Installation & Operation
Guide

www.autocue-qtv.com

Use the following steps to configure the monitor output settings:

1. Press the

F 8 key on the QBox keyboard to bring up the configuration menu.

2. Use the

D o w n arrow key to select C o n f i g u r e Q B o x and then press E n t e r .

3. Press the

R i g h t arrow key to select D i s p l a y S e t t i n g s .

Press

E n t e r to view the configuration options for your monitor from which you can

choose the appropriate video output signal.

4. Select the setting for your monitor type and signal standard. Use the

T a b key to move

through the list and use the Space bar to select the appropriate setting.
