Rockwell Automation GV3000/SE AC Drive 1-20HP, 230VAC Ver. 6.04 Hdwe Ref, Install, Troubleshooting User Manual

Page 78

A-2

GV3000/SE 230 VAC 1-20 HP Drive, Hardware Reference Version 6.04

Table A.3 – Terminal Strip Input Specifications

Signal Type

Speed Reference Input

Terminal(s)

12-15

Specification

5 KW potentiometer (0 to +/– 10 VDC
@ 50 Kilohms input
impedance) or 0-20 mA (@250 Ohms
input impedance) with
10-bit resolution. (Jumper-selectable
by jumper J4; refer to section 2.4.1.)

Note that the drive provides +15 VDC
buffered through a 1.875 Kilohms
resistor.

+24 VDC Isolated Supply

Remote/Local (Default)

Ramp1/Ramp2 (Default)

Forward/Reverse (Default)

Function Loss

Run/Jog

Reset

Stop

Start

Table A.4 – Terminal Strip Output Specifications

Signal Type

Analog Output

Snubber Resistor

Terminal(s)

10 - 11

scaled signal

26-27

Specification

0-10 VDC or 4-20 mA

Used with older Snubber Resistor
Braking Kits such as M/N 2DB2010
series that requires a gate turn-on
signal from the drive.

Table A.2 – Environmental Condition

Condition

Operating Temperature (Ambient)

Storage Temperature (Ambient)

Humidity

Specification

to 40

C (32

to 104

-40

to 65

C (-40

to 149

5 to 95% non-condensing
