2-2

GV3000/SE 230 VAC 1-20 HP Drive, Hardware Reference Version 6.04

Table 2.1 – Power Ratings

Model

Number

1V2160
1V2460
2V2160
2V2460
3V2160

3V2460

5V2160

5V2460

7V2160

7V2260

10V2160
10V2260
15V2160
15V2260
20V2160
20V2260

Input Volts

(AC)

200-230 VAC

+/– 10%

200-230 VAC

+/– 10%

200-230 VAC

+/– 10%

200-230 VAC

+/– 10%

200-230 VAC

+/– 10%

200-230 VAC

+/– 10%

200-230 VAC

+/– 10%

200-230 VAC

+/– 10%

Input

KVA

2.4

3.7

5.5

9.6

12.7

15.5

24.1

29.8

Input Amps

(Maximum)

6.1 A

9.4 A

13.8 A

24.2 A

31.9 A

39.0 A

60.5 A

75.0 A

Output Amps

(Maximum)

(1)

5.1 A

8.5 A

12.3 A

21.0 A

26.9 A

35.0 A

53.3 A

69.6 A

Power Loss Watts

(Full Load)

60

100

140

180

210

250

375

600

(1)

With vector regulation, 150% output current capability for one minute.

2.2 NEMA Enclosures

Each of the GV3000/SE Power Modules have one of the following NEMA ratings:

NEMA1: Vented. Contains a communication access door that allows access to
the communication port without removing the cover. Intended for
general-purpose indoor applications.

NEMA 4X/12: Not vented. Supplied with base and keypad gaskets. Intended
for use in indoor environments that require a water-tight/dust-tight enclosure.
An enclosure with this NEMA rating encompasses both ratings (4X and 12).

NEMA 12: Intended for use in indoor environments that require a dust-tight/
drip-tight enclosure.

See table 2.1 for a listing of the Power Modules and their individual NEMA ratings.

NEMA

Rating

1

4X/12

1

4X/12

1

4X/12

1

4X/12

1

12

1

12

1

12

1

12
