User wire routing, Bottom view – Rockwell Automation GV3000/SE AC Drive 1-20HP, 230VAC Ver. 6.04 Hdwe Ref, Install, Troubleshooting User Manual
Page 40
4-4
GV3000/SE 230 VAC 1-20 HP Drive, Hardware Reference Version 6.04
Figure 4.2 – Wire Routing Locations for 7.5 and 10 HP Drives
MOTOR LEADS
- OR -
INPUT POWER
AND MOTOR LEADS
INPUT POWER
- OR -
SNUBBER RESISTOR
BRAKING
SIGNAL CONTROL
(TERMINAL STRIP)
COVER
BASE
(3) 3/4" NPT
CONDUIT HUBS (NEMA 12).
-OR-
(3) 0.875 [22.2 mm] DIA.
HOLES (NEMA 1).
USER WIRE ROUTING
REGULATOR TERMINAL
STRIP
POWER TERMINAL
STRIP
AUTO
MAN
Forward
Reverse
PROGRAM
RUN
JOG
ENTER
STOP
RESET
START
SPEED
VOLTS
AMPS
Hz
Kw
TORQUE
Password
RUNNING
REMOTE
JOG
AUTO
FORWARD
REVERSE
PROGRAM
. . . .
16 20
GROUND TERMINALS
(1) 1/2" NPT
CONDUIT HUB (NEMA 12)
-OR-
(1) 0.875 [22.2 mm] DIA.
HOLES (NEMA 1).
Bottom View
