Rockwell Automation GV3000/SE AC Drive 1-20HP, 230VAC Ver. 6.04 Hdwe Ref, Install, Troubleshooting User Manual
Page 58
7-8
GV3000/SE 230 VAC 1-20 HP Drive, Hardware Reference Version 6.04
Figure 7.3 – Encoder Wiring Connections
REAR OF ENCODER CONNECTOR
Tamagawa FA Style
(M/N 2TC4025 and 2TC4075)
WHITE/ORANGE
ORANGE
BROWN
WHITE/BROWN
WHITE/GREEN
GREEN
1 2 3 4
5 6 7 8 9
10 11 12 13
14 15 16
REAR OF ENCODER CONNECTOR
Dynapar H20 Style
(M/N 2TC3025 and 2TC3075)
WHITE/ORANGE
ORANGE
RED
WHITE/RED
BROWN
WHITE/BROWN
B I G
A H
C J F
D E
REAR OF ENCODER CONNECTOR
Lakeshore SL56 and RL67 Style Slim-Tach Encoder
Regulator
Terminal Strip
WHITE/ORANGE
ORANGE
RED
WHITE/RED
BROWN
WHITE/BROWN
1
2
3
4
5
6
7
8
9
10
Terminal 6
Terminal 5
Terminal 4
Terminal 9
Terminal 7
Terminal 8
Regulator
Terminal Strip
Terminal 6
Terminal 5
Terminal 4
Terminal 9
Terminal 7
Terminal 8
Regulator
Terminal Strip
Terminal 6
Terminal 5
Terminal 4
Terminal 9
Terminal 8
Terminal 7
Connector/Cable End
Pin 3
Phase A
Pin 2
Phase B
Pin 7
Phase B Not
Pin 8
Phase A Not
Pin 1
0 VDC
Pin 6
+15 VDC
Connector/Cable End
Pin A
Phase A
Pin B
Phase B
Pin I
Phase B Not
Pin H
Phase A Not
Pin F
0 VDC
Pin D
+15 VDC
Connector/Cable End
Pin 1
Phase A
Pin 8
Phase B
Pin 9
Phase B Not
Pin 2
Phase A Not
Pin 6
0 VDC
Pin 12
+15 VDC
