Rockwell Automation GV3000/SE AC Drive 1-20HP, 230VAC Ver. 6.04 Hdwe Ref, Install, Troubleshooting User Manual
Page 75
9-5
Troubleshooting the Drive
Table 9.4 – Replacement Parts for 15-20 HP Drives
Power Module
Part Number
907005
907006
907009
907012
907015
907003
0-56921-6xx
827705
827706
Description
Fan Assembly for NEMA 1
Fan Assembly for NEMA 12
NEMA 1 Cover
NEMA 12 Cover/Gasket
Membrane Switch Keypad/Bracket
Internal Fan Assembly
Regulator PCB
Base Board (PISC-20)
Base Board (GVPB-20)
15V2160
15V2260
2
2
1
1
1
1
1
1
1
20V2160
20V2260
2
2
1
1
1
1
1
1
1
