3-8
GV3000/SE 230 VAC 1-20 HP Drive, Hardware Reference Version 6.04
Model Number
1V2160
1V2460
2V2160
2V2460
3V2160
3V2460
5V2160
5V2460
7V2160
7V2260
10V2160
10V2260
15V2160
15V2260
20V2160
20V2260
Horsepower
Rating
1 HP
2 HP
3 HP
5 HP
7.5 HP
10 HP
15 HP
20 HP
Input AC Fuse
Rating (1)
12 A
15 A
20 A
40 A
50 A
70 A
100 A
125 A
Table 3.9 – AC Input Line Fuse Selection Values
(1) Recommended fuse type: UL Class J, 600V, time-delay, or equivalent.
3.2.4 Meeting Encoder Specifications (FVC Regulation Only)
GV3000/SE drives set up for FVC regulation require an encoder for closed loop
operation. Encoder specifications are provided in table A.6. Drives set up for V/Hz
or SVC regulation do not require an encoder for feedback because they operate in
open loop mode.
3.2.4.1 Encoder Wiring Guidelines
Encoder connections are considered signal level wiring and, therefore, must be run
separate from control and power wiring. Reliance Electric recommends 18 AWG
unshielded twisted pair wires with 2-3 twists per inch for applications to a maximum
distance of 303 meters (1000 feet). The recommended Reliance Electric part
number is 417900-207CG, 18 AWG, 6 conductor (3 twisted pairs).
3.2.5 Verifying Power Module Output Current Rating is Greater Than
Motor Full Load Amps
Verify that the GV3000/SE output current rating is greater than the motor's full load
current (amps). Table 2.1 lists the output current values.
