9-4 GV3000/SE 230 VAC 1-20 HP Drive, Hardware Reference Version 6.04
Power Module
Part Number
907004
907006
907007
907010
907013
907001
0-56921-6xx
827003
827701
Description
Fan Assembly for NEMA 1
Fan Assembly for NEMA 4X/12
NEMA 1 Cover
NEMA 4X/12 Cover/Gasket
Membrane Switch Keypad/Bracket
Internal Fan Assembly
Regulator PCB
Base Board (PISC-3)
Base Board (PISC-5)
1V2160
1V2460
1
1
1
1
1
1
1
1
–
9.5 Replacement Parts
Tables 9.2 to 9.4 list the replacement parts that are available from Reliance Electric.
See figures 2.2 to 2.4 for the location of the parts.
Table 9.2 – Replacement Parts for 1-5 HP Drives
2V2160
2V2460
1
1
1
1
1
1
1
1
–
3V2160
3V2460
1
1
1
1
1
1
1
1
–
5V2160
5V2460
1
1
1
1
1
1
1
–
1
Table 9.3 – Replacement Parts for 7.5-10 HP Drives
Power Module
Part Number
907004
907006
907008
907011
907014
907002
0-56921-6xx
827703
Description
Fan Assembly for NEMA 1
Fan Assembly for NEMA 12
NEMA 1 Cover
NEMA 12 Cover/Gasket
Membrane Switch Keypad/Bracket
Internal Fan Assembly
Regulator PCB
Base Board (PISC-10)
7V2160
7V2260
2
2
1
1
1
1
1
1
10V2160
10V2260
2
2
1
1
1
1
1
1
