Chapter 4
Configuring Your Decoder
4–46
16) Press the [SPACE] bar until the Match Entry option is displayed. Press
[RETURN]. Use the right arrow key to select the output time field, press the
[SPACE] key, enter a value of 10 (10 milliseconds), and then press the
[RETURN] key:
-- SYMBOLOGY -- -------- LENGTHS -------- -------- SCANNER CONTROL --------
CODE 39: Yes 00 00 00 00 00 00 00 00 LASER-ON MODE: Continuous
I 2-OF-5: No 00 00 00 00 00 00 00 00 DECODE TRIGGER: Package Detect
CODE 128: No 00 00 00 00 00 00 00 00 CAPTURE COUNT: 2 (scans)
CODABAR: No 00 00 00 00 00 00 00 00 FIELDS/SCAN: 1
UPC-A: No FIELDS/PACKAGE: 1
UPC-E: No NO-READ TIMER: 0000 (msec)
EAN-8: No INTER-SCAN TIMER: 0000 (msec)
EAN-13: No MATCH COMPLETE: 1
------------MATCH CODE TABLE-------------- --------- OUTPUTS [DISABLED]---------
1) I 2-OF-5 Y
1234 Match Entry 0010
2) CODE 39 N None 0000
3) CODE 39 N None 0000
4) CODE 39 N None 0000
5) CODE 39 N None 0000
6) CODE 39 N None 0000
7) CODE 39 N None 0000
8) CODE 39 N None 0000
Commands: ESC Change: SPACE Cursor Control: ARROWS
17) Press the [ESC] key to select the command bar, press the [SPACE] key
until the SAVE command is highlighted:
-- SYMBOLOGY -- -------- LENGTHS -------- -------- SCANNER CONTROL --------
CODE 39: Yes 00 00 00 00 00 00 00 00 LASER-ON MODE: Continuous
I 2-OF-5: No 00 00 00 00 00 00 00 00 DECODE TRIGGER: Package Detect
CODE 128: No 00 00 00 00 00 00 00 00 CAPTURE COUNT: 2 (scans)
CODABAR: No 00 00 00 00 00 00 00 00 FIELDS/SCAN: 1
UPC-A: No FIELDS/PACKAGE: 1
UPC-E: No NO-READ TIMER: 0000 (msec)
EAN-8: No INTER-SCAN TIMER: 0000 (msec)
EAN-13: No MATCH COMPLETE: 1
------------MATCH CODE TABLE-------------- --------- OUTPUTS [DISABLED]---------
1) I 2-OF-5 Y
1234 Match Entry 0010
2) CODE 39 N None 0000
3) CODE 39 N None 0000
4) CODE 39 N None 0000
5) CODE 39 N None 0000
6) CODE 39 N None 0000
7) CODE 39 N None 0000
8) CODE 39 N None 0000
Commands: ESC Chan: SPACE Cursor Control: ARROWS
NEXT PAGE THIS PAGE RECALL SAVE DEFAULT
