B - default parameters of decoder, Default parameters of decoder – Rockwell Automation 2755-DM9, -DM9E High Speed Decoder User Manual
Page 143

A–B
B
Appendix
B–1
Default Parameters of Decoder
The following table lists the factory set default parameters of the
decoder.
Type
Default Parameters
Message Format
Send Bar Code Data:
Yes
Send Package Count:
No
Send Bar Code Type:
No
Send Source Identifier:
No
Send Header Message:
No
Send No–Read Message:
No
Expand UPC–E:
Yes
Source Identifier:
None
Label Delimiter:
None
Start Character:
None
End Message:
CRLF
Transmission Check:
None
Header Message:
None
No–Read Message:
None
Code 39 Check Character:
No
Send:
No
I 2–of–5 Check Character:
No
Send:
No
Codabar Check Character:
No
Send:
No
Host Communication Parameters
Baud rate:
9600
Bits/Char:
8 Data, 1 Stop
Parity:
None
ACK Character:
None
NAK Character:
None
Start Scan Character:
None
Stop Scan Character:
None
Large Buffer:
No
Response Mode:
End Of Trigger
Host Protocol:
RS–232
Device Address:
01
Package Detect Input
Filter:
No
Sense:
Lo = Package
Bar Code Type
Code 39:
Enabled
Interleaved. 2–of 5:
Disabled
Code 128:
Disabled
Codabar:
Disabled
UPC–A:
Disabled
UPC–E:
Disabled
EAN–8:
Disabled
EAN–13:
Disabled
Bar Code Lengths
Code 39:
00, 00, 00, 00, 00, 00, 00, 00
Interleaved. 2–of 5:
00, 00, 00, 00, 00, 00, 00, 00
Code 128:
00, 00, 00, 00, 00, 00, 00, 00
Codabar:
00, 00, 00, 00, 00, 00, 00, 00
