Rockwell Automation 2755-DM9, -DM9E High Speed Decoder User Manual
Page 69
Chapter 4
Configuring Your Decoder
4–42
8) Press the [SPACE] key to display the the Valid Package response mode:
------- MESSAGE FORMAT ------- ------- HOST COMM -------
SEND BAR CODE DATA:
Yes
BAUD RATE:
9600
SEND PACKAGE COUNT:
No
BITS/CHAR:
8 Data, 1 Stop
SEND BAR CODE TYPE:
No
PARITY:
None
SEND SOURCE IDENTIFIER:
No
SEND HEADER MESSAGE:
No
ACK CHAR:
None
SEND NO-READ MESSAGE:
Yes
NAK CHAR:
None
START SCAN CHAR:
None
EXPAND UPC-E:
Yes
STOP SCAN CHAR:
None
SOURCE IDENTIFIER:
LARGE BUFFER:
No
LABEL DELIMITER:
None
RESPONSE MODE:
Valid Package
START CHAR:
None
HOST PROTOCOL:
RS232
END MESSAGE:
CRLF
DEVICE ADDRESS:
01
TRANSMISSION CHECK:
None
HEADER MESSAGE:
NO-READ MESSAGE:
CODE 39 CHECK CHAR:
No SEND: No ---PACKAGE DETECT INPUT---
I 2-OF-5 CHECK CHAR:
No SEND: No FILTER: No
CODABAR CHECK CHAR:
No SEND: No SENSE: LO = Package
SELECT -- Cancel: ESC Change: SPACE Enter: RETURN
9) Press the [RETURN] key to enter the value and use [RETURN] and arrow
keys to position the cursor at the NO-READ MESSAGE field. Press the
[SPACE] bar. Type a NO-READ message into the empty field:
------- MESSAGE FORMAT ------- ------- HOST COMM -------
SEND BAR CODE DATA:
Yes
BAUD RATE:
9600
SEND PACKAGE COUNT:
No
BITS/CHAR:
8 Data, 1 Stop
SEND BAR CODE TYPE:
No
PARITY:
None
SEND SOURCE IDENTIFIER:
No
SEND HEADER MESSAGE:
No
ACK CHAR:
None
SEND NO-READ MESSAGE:
Yes
NAK CHAR:
None
START SCAN CHAR:
None
EXPAND UPC-E:
Yes
STOP SCAN CHAR:
None
SOURCE IDENTIFIER:
LARGE BUFFER:
No
LABEL DELIMITER:
None
RESPONSE MODE:
Valid Package
START CHAR:
None
HOST PROTOCOL:
RS232
END MESSAGE:
CRLF
DEVICE ADDRESS:
01
TRANSMISSION CHECK:
None
HEADER MESSAGE:
NO-READ MESSAGE:
NO-READ
CODE 39 CHECK CHAR:
No SEND: No ---PACKAGE DETECT INPUT---
I 2-OF-5 CHECK CHAR:
No SEND: No FILTER: No
CODABAR CHECK CHAR:
No SEND: No SENSE: LO = Package
EDIT -- Cancel: ESC Enter: RETURN Erase Char: Backspace
