Chapter 4
Configuring Your Decoder
4–10
Depending upon the type of field (select or edit) that you are configuring, use
the commands listed in Table 4.A:
To do this:
You must:
Comments
Return to SELECT OPERATION
menu.
Press the [ESC] key to select the
command bar and then press the [ESC]
key again.
Change any field.
Press [SPACE] bar.
In select fields, next option is
displayed.
In edit fields, field is cleared and new
data can be entered.
Enter a new or different value.
Press [RETURN] key.
New value is highlighted in reverse
video.
Move to a different field.
Press [RETURN] key or arrow keys.
①
See note
①
below.
Move to next menu.
Press [ESC] key to select the command
bar and press the [RETURN] key.
Transfer new parameters into the
Decoder’s memory (EEPROM).
SAVE
Press [ESC] key to select command bar.
Use [SPACE] bar to select SAVE and
press the [RETURN] key. Press [Y] key
at confirmation prompt.
New configuration parameters are
transferred to the decoder’s
EEPROM.
Recall previously set parameters
from the Decoder’s memory
(EEPROM–User Definable).
RECALL
Press [ESC] key to select command bar.
Use [SPACE] bar to select RECALL and
press the [RETURN] key. Press [Y] key
at confirmation prompt.
Previously set parameters are
displayed.
Reset decoder to factory set
parameters (EPROM–Defaults).
DEFAULT
Press [ESC] key to select command bar.
Use [SPACE] bar to select DEFAULT
and press the [RETURN] key. Press [Y]
key at confirmation prompt.
Refer to Appendix B for factory set
parameters.
①
Allen-Bradley Industrial Terminals (Catalog Number 1770-T1, -T2, or -T3) do not have arrow keys. Use the [CTRL] and U, D, L or R keys for Up, Down, Left or Right cursor
movement.
EDIT FIELDS - There are three types of data that can be entered or
modified in an edit field:
1) ASCII character codes-(decimal values 0 to 255)
2) Numeric values
3) Text strings
To open an edit field for a change, press the [SPACE] key. The cleared field
will appear as a block in reverse video and the decoder will display the edit
keys you can use at the bottom of the screen. All other keys will be ignored:
EDIT -- Cancel:ESC Enter:RETURN Erase Char: BACKSPACE
