Appendix D
Configuration Areas of Memory
D–7
PCCC
Address
Configuration Parameter
Number
of Bytes
(* = Default)
Acceptable Values
57Ah Bar Code Type in Match Code Table Entry 7 1 0 = *Code 39
1 = Interleaved 2 of 5
2 = Codabar
3 = UPC–A
4 = UPC–E
5 = EAN–8
6 = EAN–13
7 = Code 128
57Bh Enable Match Dode Table Entry 7 1 0 = *No
1 = Yes
57Ch Match Code 7) Length
Match Code 7) String 1
32
0–32, 0 = *empty
32 Characters
59Dh Output Condition 7 1 0 = *None
1 = Read (Package)
2 = No–Read (Package)
3 = Match–Complete
4 = Match Entry
5 = Read and No–Match
6 = No–Read or No–Match
7 = Auto Load
59Eh Output Pulse 7) Duration 2 *0, 10 – – – 9999
5A0h Bar Code Type in Match Code Table Entry 8 1 0 = *Code 39
1 = Interleaved 2 of 5
2 = Codabar
3 = UPC–A
4 = UPC–E
5 = EAN–8
6 = EAN–13
7 = Code 128
5A1h Enable Match Code Table Entry 8 1 0 = *No
1 = Yes
5A2h Match Code 8) Length
Match Code 8) String 1
32
0–32, 0 = *empty
32 Characters
5C3h Output Condition 8 1 0 = *None
1 = Read (Package)
2 = No–Read (Package)
3 = Match–Complete
4 = Match Entry
5 = Read and No–Match
6 = No–Read or No–Match
7 = Auto Load
8 = Auto Load (INPUT)
5C4h Output Pulse 8) Duration 2 *0, 10 – – – 9999
5C4h Last Valid Address in Configuration Area
