Page 31

Chapter 4
Configuring Your Decoder
4–4
After selecting the CRT type, the following Select Operation menu will
appear:
2755-DM9 Bar Code Reader VX.XX
Copyright 1990 Allen-Bradley Company, Inc.
SELECT OPERATION
1) Display Bar Code Labels
2) Display Status and Counters
3) Display/Change Configuration
4) Reset Status and Counters
5) Restart
6) Select Language
Press 1, 2, 3, 4, 5, 6, or ESC
The following are explanations of each operation listed on the Select
Operation menu:
1) Display Bar Code Labels - This operating mode allows you to monitor
bar code labels as they are being scanned. After selecting this operation by
pressing the [1] key, bar code labels will be displayed as they are decoded.
The display will scroll up as new labels appear on the bottom of the screen.
If more than one label is decoded on the same scan, the labels will be
displayed on the same line separated by a space. If a no-read condition
occurs, the decoder will display the no-read message that you enter as part of
the decoder configuration. Pressing the [ESC] key will exit this function.
The following is an example of how the display bar code labels screen might
appear:
