Chapter 4
Configuring Your Decoder
4–40
The decoder will display:
------- MESSAGE FORMAT ------- ------- HOST COMM -------
SEND BAR CODE DATA: Yes BAUD RATE: 9600
SEND PACKAGE COUNT: No BITS/CHAR: 8 Data, 1 Stop
SEND BAR CODE TYPE: No PARITY: None
SEND SOURCE IDENTIFIER: No
SEND HEADER MESSAGE: No ACK CHAR: None
SEND NO-READ MESSAGE: No NAK CHAR: None
START SCAN CHAR: None
EXPAND UPC-E: Yes STOP SCAN CHAR: None
SOURCE IDENTIFIER: LARGE BUFFER: No
LABEL DELIMITER: None RESPONSE MODE: End of Trigger
START CHAR: None HOST PROTOCOL: RS232
END MESSAGE: CRLF DEVICE ADDRESS: 01
TRANSMISSION CHECK: None
HEADER MESSAGE:
NO-READ MESSAGE:
CODE 39 CHECK CHAR: No SEND: No ---PACKAGE DETECT INPUT---
I 2-OF-5 CHECK CHAR: No SEND: No FILTER: No
CODABAR CHECK CHAR: No SEND: No SENSE: LO = Package
Commands: ESC Change: SPACE Cursor Control: ARROWS
Note: Different values or selections may appear depending upon the previous
programming of your decoder
5) In this example we want to enter a SEND NO-READ message and set the
decoder response mode to After Valid Package. To do this, press the down
arrow or [RETURN] key five times until the SEND NO-READ MESSAGE
field is highlighted in reverse video:
------- MESSAGE FORMAT ------- ------- HOST COMM -------
SEND BAR CODE DATA: Yes BAUD RATE: 9600
SEND PACKAGE COUNT: No BITS/CHAR: 8 Data, 1 Stop
SEND BAR CODE TYPE: No PARITY: None
SEND SOURCE IDENTIFIER: No
SEND HEADER MESSAGE: No ACK CHAR: None
SEND NO-READ MESSAGE: No NAK CHAR: None
START SCAN CHAR: None
EXPAND UPC-E: Yes STOP SCAN CHAR: None
SOURCE IDENTIFIER: LARGE BUFFER: No
LABEL DELIMITER: None RESPONSE MODE: End of Trigger
START CHAR: None HOST PROTOCOL: RS232
END MESSAGE: CRLF DEVICE ADDRESS: 01
TRANSMISSION CHECK: None
HEADER MESSAGE:
NO-READ MESSAGE:
CODE 39 CHECK CHAR: No SEND: No ---PACKAGE DETECT INPUT---
I 2-OF-5 CHECK CHAR: No SEND: No FILTER: No
CODABAR CHECK CHAR: No SEND: No SENSE: LO = Package
Commands: ESC Change: SPACE Cursor Control: ARROWS
